CuZn10 (CW501L)
| Qib: | CuZn10 |
| Tus lej: | qw 501l |
| Kev faib tawm: | Tooj-zinc alloy |
| Qhov ntom | 8.8g / cm3 |
| Txheem: | TS EN 1652: 1998 Copper thiab tooj liab alloys Phaj, ntawv, sawb thiab voj voog rau kev siv dav dav TS EN 12163: 1998 Copper thiab tooj liab alloys Qws rau lub hom phiaj dav dav TS EN 12166: 1998 Copper thiab tooj liab alloys Hlau rau lub hom phiaj dav dav TS EN 12449: 1999 Copper thiab tooj liab alloys Seamless, round raj rau lub hom phiaj dav dav TS EN 13148: 2001 Copper thiab tooj liab alloys Kub-dip tinned strip |
| Qib sib npaug: | Mus ntawm no |
Tshuaj muaj pes tsawg leeg % ntawm qib CuZn10 (CW501L)
| Fe | Ni | Al | Cu | Pb | Sn | Lwm tus | - |
| max 0.05 | max 0.3 | max 0.02 | 89 - 91 | max 0.05 | max 0.1 | tag nrho 0.1 | Zn - lwm |
Mechanical zog ntawm qib CuZn10 (CW501L)
| Rm- Tensile zog (MPa) (R240) | 240-290 |
| Rm- Tensile zog (MPa) (R280) | 280-360 |
| Rm- Tensile zog (MPa) (R350) | 350 |
| Rp0.20.2% pov thawj lub zog (MPa) (R240) | 140 |
| Rp0.20.2% pov thawj lub zog (MPa) (R280) | 200 |
| Rp0.20.2% pov thawj lub zog (MPa) (R350) | 290 |
| A- Min. elongation ntawm pob txha (%) (R240) | 45 |
| A- Min. elongation ntawm pob txha (%) (R280) | 20 |
| A- Min. elongation ntawm pob txha (%) (R350) | 8 |
| A- Min. elongation Lo=50 hli (%) (R240) | 36 |
| A- Min. elongation Lo=50 hli (%) (R280) | 13 |
| A- Min. elongation Lo=50 hli (%) (R350) | 4 |
| Vickers hardness (HV): (H050) | 50 - 80 |
| Vickers hardness (HV): (H080) | 80 - 110 |
| Vickers hardness (HV): (H110) | 110 |
Qib sib npaug ntawm qib CuZn10 (CW501L)
Ceeb toom! Tsuas yog siv tau
| EU EN |
Lub teb chaws Yelemees DIN, NWS |
Russia GOST |
|||
| CuZn10 |
|
|
Casting txheej txheem
| GS | Xuab zeb casting |
| GM | Permanent pwm casting |
| GZ | Centrifugal casting |
| GC | Nruam casting |
| GP | Siab tuag casting |
Khoom siv
| R | Cov khoom siv los ntawm qhov tsawg kawg nkaus tus nqi ntawm tensile lub zog yuav tsum tau rau cov khoom uas yuav tsum tau tensile zog thiab elongation yuav tsum tau |
| H | Cov khoom siv raws li qhov tsawg kawg nkaus tus nqi ntawm hardness yuav tsum tau rau cov khoom uas yuav tsum tau hardness yuav tsum tau |
Mechanical zog
| ReH | Yam tsawg kawg nkaus yield zog / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale |
| Rm | Tensile zog / Zugfestigkeit / Resistance a la traction |
| A | Tsawg kawg elongation / Mindestwert der Bruchdehnung / Allongement tsawg |
| J | Kev ntsuas qhov cuam tshuam / Kerbschlagbiegeversuch / Essai de flexion par choc |
|
CuZn10 (CW501L) tooj liab-zinc alloy |
