ASTM B550 Zirconium Alloy Bar Thiab Hlau
Qhov kev qhia tshwj xeeb no suav nrog peb qib ntawm zirconium thiab zirconium alloy bar thiab hlau: qib R60702, zirconium unalloyed; qib R60704, zirconium tin; thiab qib R60705, zirconium niobium. Tshuaj muaj pes tsawg leeg; thiab cov cuab yeej cuab yeej cuab tam xws li tensile lub zog, yield zog thiab elongation.
Lub zirconium & zirconium alloy bar thiab hlau yog tsim los rau ASTM B550 npog peb qib: Qib R60702: zirconium unalloyed, Qib R60704: zirconium-tin, Qib R60705: zirconium-niobium. Cov khoom siv tuaj yeem ua tiav kub lossis txias tiav, feem ntau nyob rau hauv annealed mob. Lub Zr & Zr alloy bar los yog hlau tej zaum yuav muab nyob rau hauv round, square, octagon, hexagon los yog ca duab. Feem ntau, cov khoom xa tuaj muaj xws li tsis-descaled, descaled, descaled & pickled, tig, av los yog polished.
Cov Neeg Siv Khoom Tshwj Xeeb Hlau - GNEE
Bar: kub dov, forged, los yog txias ua hauj lwm semi-tiav khoom seem khoom uas nws cross sectional cheeb tsam yog sib npaug zos rau los yog tsawg dua 16 nti2 [10323 mm2]; Cov duab plaub yuav tsum tsawg dua lossis sib npaug li 10 nti [254 mm] hauv qhov dav thiab ntau dua 0.1875 nti [4.8 mm] hauv thickness.
Hlau: puag ncig, tiaj tus, lossis cov duab tshwj xeeb tsawg dua lossis sib npaug rau 0.1875 nti [4.8 mm] hauv tuab lossis loj loj.
Chemical Composition Requirements
| Element | ASTM B550 Zr & Zr Alloy Qib | ||
| R60702 | R60704 | R60705 | |
| Zirconium (+ Hf) | Ntau dua lossis sib npaug rau 99.2 | Ntau dua lossis sib npaug rau 97.5 | Ntau dua lossis sib npaug rau 95.5 |
| Hafnium | Tsawg dua lossis sib npaug li 4.5 | Tsawg dua lossis sib npaug li 4.5 | Tsawg dua lossis sib npaug li 4.5 |
| Hlau + Chromium | Tsawg dua lossis sib npaug rau 0.2 | 0.2~0.4 | Tsawg dua lossis sib npaug rau 0.2 |
| Tin | - | 1.0~2.0 | - |
| Hydrogen | Tsawg dua lossis sib npaug rau 0.005 | Tsawg dua lossis sib npaug rau 0.005 | Tsawg dua lossis sib npaug rau 0.005 |
| Nitrogen | Tsawg dua lossis sib npaug rau 0.025 | Tsawg dua lossis sib npaug rau 0.025 | Tsawg dua lossis sib npaug rau 0.025 |
| Cov pa roj carbon | Tsawg dua lossis sib npaug rau 0.05 | Tsawg dua lossis sib npaug rau 0.05 | Tsawg dua lossis sib npaug rau 0.05 |
| Niobium | - | - | 2.0~3.0 |
| Oxygen | Tsawg dua lossis sib npaug rau 0.16 | Tsawg dua lossis sib npaug rau 0.18 | Tsawg dua lossis sib npaug rau 0.18 |
Mechanical Properties ntawm Zr & Zr Alloy Bar thiab Hlau
| ASTM B 550 Cov Lus Qhia Tshwj Xeeb | Tensile zog, min. | Yield zog, min. | Elongation | ||
|---|---|---|---|---|---|
| Qib | ksi ua | MPa | ksi ua | MPa | min. % |
| R60702 | 55 | 380 | 30 | 205 | 16 |
| R60704 | 60 | 415 | 35 | 240 | 14 |
| R60705 | 80 | 550 | 55 | 380 | 16 |
Peb Cov Khoom Siv
Kev sim
Tension Tests-Qhov kev ntsuam xyuas nruj yuav tsum ua raws li Txoj Kev Xeem E8. Txiav txim siab lub zog tawm los ntawm qhov offset (0.2%) txoj kev. Txiav txim siab lub zog tensile siv tus nqi strain ntawm 0.003 txog 0.007 in./in. [mm/mm]/min los ntawm lub zog tawm los. Tom qab lub zog tawm los tau dhau lawm, tus ntoo khaub lig-lub taub hau ceev yuav nce mus txog kwv yees li 0.05 in./in. [mm/mm]/min mus ua tsis tiav.
Chemical Tests-Cov tshuaj ntsuam xyuas tshuaj yuav tsum tau ua los ntawm cov txheej txheem txheej txheem.
